Good Quality Pigment Carbon Black for Gravure Ink
Product Description supplier raw material chemical rubber auxiliary additive carbon black Product:Carbon BlackFormula:CM
Basic Info.
Model NO. | Carbon Black |
Application Material | Wool |
Type | Natural |
Solubility | Solubility |
Composition | C |
Molecular Weight | 12.00 |
Structural Formula | C |
Product Name | Carbon Black 410(Pbl7) |
Type1 | Synthetic |
Transport Package | 10kg Bags |
Specification | (DEGUSSA), (CABOT), (COLUMBIAN) |
Trademark | SG |
Origin | China |
HS Code | 32041700 |
Production Capacity | 10000tons/Month |
Product Description
Product Description
supplier raw material chemical rubber auxiliary additive carbon blackProduct:Carbon BlackFormula:CMolecular Weight:12.0107H.S.CODE:28030000CAS.NO.:1333-86-4Standard:GB3778-2003Properties: Dark black powder, it has high tensile stress, good processing performance, high rebounding performance and high flexibility.It is widely used in various fields.
1. Grade
1)carbon black N220High abrasion resistance and crack resistance, compared with N110, fixed and low stress and low dispersion is better.Bolt-on carbon black to tire tread, high quality industrial rubber products and high load conveyor belt.2)carbon black N330With good abrasion resistance and middling lag.Tires with beam layer, the tire, solid tyres, roller outer and hose surface, industrial rubber products, car tire tread.3)carbon black N550In the soft black variety has the best reinforcing performance, excellent performance, low resilient rate.Tire body and inner tube, rubber hose, extruding bar, seal, die industrial rubber products, etc.4)carbon black N660Compared with N550, reinforcing sex is low, the structure is low, high expansion type, fill the quantity is larger.Tire body and inner tube, rubber ordinary moulding and extrusion applications, monolayer moisture system products.
2.Specification
No. | Name of ProductIndicatorsItem | N220 | N330 | N550 | N660 |
1 | Iodine Absorption Value,g/kg | 121±7 | 82±7 | 43±6 | 36±6 |
2 | DBP Absorption Value,10-5m³/kg | 114±7 | 102±7 | 121±7 | 90±7 |
3 | DBP Absorption of Compressed sample,10-5m³/kg | 90-106 | 80-96 | 77-93 | 66-82 |
4 | CTAB Absorption Area,103m2/kg | 102-120 | 73-91 | 35-49 | 29-43 |
5 | Adsorptive Specific Surface Area of Nitrogen, 103m2/kg | 106±9 | 75±9 | 39±9 | 34±9 |
6 | Nitrogen Absorption Surface Area, 103m2/kg | 112-126 | 71-85 | 34-46 | 29-41 |
7 | Tint Intensity, % | 108-124 | 96-112 | -- | -- |
8 | Decrement After Heating,%≤ | 2.5 | 2.5 | 1.5 | 1.5 |
9 | Ash, %≤ | 0.7 | 0.7 | 0.7 | 0.7 |
10 | 45µm Sieve Residue, %≤ | 0.100 | 0.100 | 0.100 | 0.100 |
11 | 150µm Sieve Residue, %≤ | 0.001 | 0.001 | 0.001 | 0.001 |
12 | Impurities | -- | -- | -- | -- |
13 | 300% Stretching Stress, Mpa≥ | -2.3±1.6 | -0.9±1.6 | -0.9±1.6 | -2.6±1.6 |
3. Application
Carbon black is a basic material with a long history, and it has been used as a coloring agent since the days before Christ.Since carbon black has nano-particles with various functions such as ultra-violet absorption and conductivity, it is still being applied to new fields such as electronic equipment and devices.Some applications of carbon black, which is a conventional yet new material, are shown below.1 ) Coloring Agent for Ink and PaintsCarbon black has higher tinting strength compared to iron black or organic pigments, and is widely used for newspaper inks, printing inks, India inks, and paints.Carbon black is also used as black pigment for inkjet ink or toners.2 ) Resin and Film Coloring AgentsCarbon black has high tinting strength and is thermally stable, and therefore it is suitable for coloring resins and films that are heat-formed.Carbon black is also excellent for absorbing ultraviolet light, providing both a superb resistance against ultraviolet rays and a coloring effect when just a small amount is mixed with resins.Carbon black is widely used for general coloring for resins and films.Resins with carbon black are used in automobile bumpers, wire coverings and steel pipe linings which require weather resistance in particular.3 ) Electric Conductive AgentCarbon black particles have the graphite-type crystalline structure, providing an excellent electric conductivity.Therefore, carbon black is widely used as conductive filler, being mixed in plastics, elastomer, paints, adhesives, films, and pastes.Fuel caps and fuel-introducing pipes of automobiles, for example, are required of electric conductivity for preventing static.Therefore, carbon black is used as an excellent antistatic agent.4 ) Electronic Equipment Related MaterialCarbon black also provides stable resistance, and therefore is used as electronic equipment related material in various display components, magnetic recording materials, and OA rolls.Furthermore, Mitsubishi Chemical has been developing carbon black with various combined functions for special applications.Our Service1. Quality control, before shipment, free sample for test. after shipment, keep sample for 3 years2. Prompt shipment with professional documents3. Packing as your request, with photo before shipment.4. Goods delivered directly from the factory warehouse after well produced in a high quality and good situation.5. Competitive price6. Testing equipment: SGS, UV, HPLC, GC, CIQ.FAQQ1: When will my order be shipped?
A: Within 3 working days after the payment.Q2: Can i get some samples?
A: Yes, contact me to know more about sample Q3: How to confirm the Product Quality before placing orders?
A: Every product is with professional COA. Please be sure about the quality.If any doubt, sample is available to you to be tested before large quantity order.Q4: How to start orders or make payments?
A: Payment by T/T, Western Union,MoneyGram etc .
